Explore the M50 standard diesel forklift with 5,000 kg rated load and 3,000 mm standard lift height. Request specifications, configuration details and a quote.
The M50 standard diesel forklift is listed with 5,000 kg rated load, 3,000 mm standard lift height and 65 kW rated engine power. Use these specifications to compare the machine with your operating requirements and request a configuration-specific quotation.
This page covers the standard M50 version. It lists 6,900 kg service weight and a 65 kW engine; compare the separate economy M50 listing if you are evaluating both versions.
| Specification | Unit | Value |
|---|---|---|
| Power Type | — | Diesel |
| Rated Load Capacity | kg | 5,000 |
| Load Center Distance | mm | 500 |
| Operator Type | — | Seated |
| Overall Length with Forks | mm | 4,305 |
| Overall Length without Forks | mm | 3,235 |
| Overall Width | mm | 1,480 |
| Overall Height, Mast Lowered | mm | 2,255 |
| Overall Height, Overhead Guard | mm | 2,290 |
| Overall Height, Mast Fully Raised | mm | 4,230 |
| Wheelbase | mm | 2,100 |
| Front Overhang | mm | 555 |
| Rear Overhang | mm | 582 |
| Front Track Width | mm | 1,180 |
| Rear Track Width | mm | 1,180 |
| Minimum Ground Clearance | mm | 150 |
| Standard Lift Height | mm | 3,000 |
| Free Lift Height | mm | N/A |
| Fork Adjustment Range | mm | N/A |
| Minimum Turning Radius | mm | 2,970 |
| Minimum Right-Angle Stacking Aisle Width | mm | 4,825 |
| Mast Tilt, Forward/Backward | ° | 6/12 |
| Maximum Lifting Speed, Unloaded | mm/s | 490 |
| Maximum Lifting Speed, Fully Loaded | mm/s | 430 |
| Maximum Travel Speed, Unloaded | km/h | 25 |
| Maximum Travel Speed, Fully Loaded | km/h | 20 |
| Gradeability, Fully Loaded | % | 20 |
| Service Weight, Unladen | kg | 6,900 |
| Number of Wheels, Drive/Steer | — | 2/2 |
| Tire Type, Front/Rear | — | Pneumatic / Pneumatic |
| Front Tire Size | — | 300-15 |
| Rear Tire Size | — | 700-12 |
| Service Brake | — | Foot Brake |
| Parking Brake | — | Hand Brake |
| Engine Model | — | Quanchai V35-88C41, China IV |
| Rated Power | kW | 65 |
| Rated Engine Speed | rpm | 2,200 |
Select the truck around the actual load weight, load centre and required lift height. Measure aisle width and doorway clearance with the intended pallet and fork arrangement. Confirm the proposed engine specification and destination-market requirements as part of the quotation.
What are the main specifications of this model?
The listed specifications include 5,000 kg rated load, 3,000 mm standard lift height and 65 kW rated engine power. Refer to the full table for dimensions and configuration details, and ask our team to confirm the specification supplied with your order.
Does rated capacity apply to every load and attachment?
The suitable working load depends on load centre, lift height, mast and attachment configuration. Provide load dimensions and handling height so the applicable capacity can be checked before purchase.
What information is needed for a quotation?
Send the required quantity, destination country or port, main working task and any attachment or site-access requirements. Include the required working height or depth and your preferred configuration so the quotation can identify the equipment and delivery terms clearly.
Compare more models in our diesel forklift range, or visit service and support for assistance.
Request a quotation for Standard Forklift M50 with your equipment and delivery requirements.
